2MHz Φ24mm outsided sticked fuel tank oil level detection transducer
Applications:
Ultrasonic flow meter, under water range detection, level measurement etc
Features:
*Rugged sealed contruction
*Cylindrical design for easy installation
Technical parameter:
Center Frequency: 2M ± 30KHz
Detectable range: 0.02 ~ 2m
Mini. parallel Resistance: 10 Ω ± 20%
Capacitance: 2300pF ± 20% @1KHz
Echo Sensitivity: 900mV echo amplitude @0.3m, under 24 Vpp
Working Voltage: Crest voltage < 300Vpp
Working temperature: -40 ~ +80℃
Pressure: ≤3Kg or 0.3MPa
Angle: Half-power angle @-3dB: 3.4° ± 0.5, Sharp Angle: 8° ± 4
Housing Material: POM
Corrosion Resistance: can be used under the environment of weak acid or weak base
Installation dimensions: 28.6mm
Protection class: IP68
Wiring instructions: contact for more details
